Daemonizing JVM-based applications

Deployment architecture design is a vital part of any custom-built server-side application development project. Due to it’s significance, deployment architecture design should commence early and proceed in tandem with other development activities. The complexity of deployment architecture design depends on many aspects, including scalability and availability targets of the provided service, rollout processes as well as technical properties of the system architecture.

Serviceability and operational concerns, such as deployment security, monitoring, backup/restore etc., relate to the broader topic of deployment architecture design. These concerns are cross-cutting in nature and may need to be addressed on different levels ranging from service rollout processes to the practical system management details.

On the system management detail level the following challenges often arise when using a pure JVM-based application deployment model (on Unix-like platforms):

  • how to securely shut down the app server or application? Often, a TCP listener thread listening for shutdown requests is used. If you have many instances of the same app server deployed on the same host, it’s sometimes easy to confuse the instances and shutdown the wrong one. Also, you’ll have to prevent unauthorized access to the shutdown listener.
  • creating init scripts that integrate seamlessly with system startup and shutdown mechanisms (e.g. Sys-V init, systemd, Upstart etc.)
  • how to automatically restart the application if it dies?
  • log file management. Application logs can be managed (e.g. rotate, compress, delete) by a log library. App server or platform logs can sometimes be also managed using a log library, but occasionally integration with OS level tools (e.g. logrotate) may be necessary.

There’s a couple of solutions to these problems that enable tighter integration between the operating system and application / application server. One widely used and generic solution is the Java Service Wrapper. The Java Service Wrapper is good at addressing the above challenges and is released under a proprietary license. GPL v2 based community licensing option is available as well.

Apache commons daemon is another option. It has its roots in Apache Tomcat and integrates well with the app server, but it’s much more generic than that, and in addition to Java, commons daemon can be used with also other JVM-based languages such as Scala. As the name implies, commons daemon is Apache licensed.

Commons daemon includes the following features:

  • automatically restart JVM if it dies
  • enable secure shutdown of JVM process using standard OS mechanisms (Tomcat TCP based shutdown mechanism is error-prone and unsecure)
  • redirect STDERR/STDOUT and set JVM process name
  • allow integration with OS init script mechanisms (record JVM process pid)
  • detach JVM process from parent process and console
  • run JVM and application with reduced OS privileges
  • allow coordinating log file management with OS tools such as logrotate (reopen log files with SIGUSR1 signal)



Deploying commons daemon

From an application developer point of view commons daemon consists of two parts: the jsvc binary used for starting applications and commons daemon Java API. During startup, jsvc binary bootstraps the application through lifecycle methods implemented by the application and defined by commons daemon Java API. Jsvc creates a control process for monitoring and restarting the application upon abnormal termination. Here’s an outline for deploying commons daemon with your application:

  1. implement commons daemon API lifecycle methods in an application bootstrap class (see Using jsvc directly).
  2. compile and install jsvc. (Note that it’s usually not good practice to install compiler toolchain on production or QA servers).
  3. place commons-daemon API in application classpath
  4. figure out command line arguments for running your app through jsvc. Check out bin/daemon.sh in Tomcat distribution for reference.
  5. create a proper init script based on previous step. Tomcat can be installed via package manager on many Linux distributions and the package typically come with an init script that can be used as a reference.



Practical experiences

Tomcat distribution includes “daemon.sh”, a generic wrapper shell script that can be used as a basis for creating a system specific init script variant. One of the issues that I encountered was the wait configuration parameter default value couldn’t be overridden by the invoker of the wrapper script. In some cases Tomcat random number generator initialization could exceed the maximum wait time, resulting in the initialization script reporting a failure, even if the app server would eventually get started. This seems to be fixed now.

Another issue was that the wrapper script doesn’t allow passing JVM-parameters with spaces in them. This can be handy e.g. in conjunction with the JVM “-XX:OnOutOfMemoryError” & co. parameters. Using the wrapper script is optional, and it can also be changed easily, but since it includes some pieces of useful functionality, I’d rather reuse instead of duplicating it, so I created a feature request and proposed tiny patch for this #55104.

While figuring out the correct command line arguments for getting jsvc to bootstrap your application, the “-debug” argument can be quite useful for troubleshooting purposes. Also, by default the jsvc changes working directory to /, in which case absolute paths should typically be used with other options. The “-cwd” option can be used for overriding the default working directory value.



Daemonizing Jetty

In addition to Tomcat, Jetty is another servlet container I often use. Using commons daemon with Tomcat poses no challenge since the integration already exists, so I decided to see how things would work with an app server that doesn’t support commons daemon out-of-the-box.

To implement the necessary changes in Jetty, I cloned the Jetty source code repository, added jsvc lifecycle methods in the Jetty bootstrap class and built Jetty. After that, I started experimenting with jsvc command line arguments for bootstrapping Jetty. Jetty comes with jetty.sh startup script that has an option called “check” for outputting various pieces of information related to the installation. Among other things it outputs the command line arguments that would be used with the JVM. This provided quite a good starting point for the jsvc command line.

These are the command lines I ended up with:

export JH=$HOME/jetty-9.2.2-SNAPSHOT
export JAVA_HOME=`/usr/libexec/java_home -v 1.8`
jsvc -debug -pidfile $JH/jetty.pid -outfile $JH/std.out -errfile $JH/std.err -Djetty.logs=$JH/logs -Djetty.home=$JH -Djetty.base=$JH -Djava.io.tmpdir=/var/folders/g6/zmr61rsj11q5zjmgf96rhvy0sm047k/T/ -classpath $JH/commons-daemon-1.0.15.jar:$JH/start.jar org.eclipse.jetty.start.Main jetty.state=$JH/jetty.state jetty-logging.xml jetty-started.xml

This could be used as a starting point for a proper production grade init script for starting and shutting down Jetty.

I submitted my code changes as issue #439672 in the Jetty project issue tracker and just received word that the change has been merged with the upstream code base, so you should be able to daemonize Jetty with Apache commons daemon jsvc in the future out-of-the-box.

Thoughts on The Reactive Manifesto

Reactive programming is an emerging trend in software development that has gathered a lot of enthusiasm among technology connoisseurs during the last couple of years. After studying the subject last year, I got curious enough to attend the “Principles of Reactive Programming” course on Coursera (by Odersky, Meijer and Kuhn). Reactive advocates from Typesafe and others have created The Reactive Manifesto that tries to formulate the vocabulary for reactive programming and what it actually aims at. This post collects some reflections on the manifesto.

According to The Reactive Manifesto systems that are reactive

  • react to events – event-driven nature enables the following qualities
  • react to load – focus on scalability by avoiding contention on shared resources
  • react to failure – resilient systems that are able to recover at all levels
  • react to users – honor response time guarantees regardless of load

Event-driven

Event-driven applications are composed of components that communicate through sending and receiving events. Events are passed asynchronously, often using a push based communication model, without the event originator blocking. A key goal is to be able to make efficient use of system resources, not tie up resources unnecessarily and maximize resource sharing.

Reactive applications are built on a distributed architecture in which message-passing provides the inter-node communication layer and location transparency for components. It also enables interfaces between components and subsystems to be based on loosely coupled design, thus allowing easier system evolution over time.

Systems designed to rely on shared mutable state require data access and mutation operations to be coordinated by using some concurrency control mechanism, in order to avoid data integrity issues. Concurrency control mechanisms limit the degree of parallelism in the system. Amdahl’s law formulates clearly how reducing the parallelizable portion of the program code puts an upper limit to system scalability. Designs that avoid shared mutable state allow for higher degrees of parallelism and thus reaching higher degrees of scalability and resource sharing.

Scalable

System architecture needs to be carefully designed to scale out, as well as up, in order to be able to exploit the hardware trends of both increased node-level parallelism (increased number of CPUs and nb. of physical and logical cores within a CPU) and system level parallelism (number of nodes). Vertical and horizontal scaling should work both ways, so an elastic system will also be able to scale in and down, thereby allowing to optimize operational cost structures for lower demand conditions.

A key building block for elasticity is achieved through a distributed architecture and the node-to-node communication mechanism, provided by message-passing, that allows subsystems to be configured to run on the same node or on different nodes without code changes (location transparency).

Resilient

A resilient system will continue to function in the presence of failures in one or more parts of the system, and in unanticipated conditions (e.g. unexpected load). The system needs to be designed carefully to contain failures in well defined and safe compartments to prevent failures from escalating and cascading unexpectedly and uncontrollably.

Responsive

The Reactive manifesto characterizes the responsive quality as follows:

Responsive is defined by Merriam-Webster as “quick to respond or react appropriately”.

Reactive applications use observable models, event streams and stateful clients.

Observable models enable other systems to receive events when state changes.

Event streams form the basic abstraction on which this connection is built.

Reactive applications embrace the order of algorithms by employing design patterns and tests to ensure a response event is returned in O(1) or at least O(log n) time regardless of load.

Commentary

If you’ve been actively following software development trends during the last couple of years, ideas stated in the reactive manifesto may seem quite familiar to you. This is because the manifesto captures insights learned by the software development community in building internet-scale systems.

One such set of lessons stems from problems related to having centrally-stored state in distributed systems. The tradeoffs of having a strong consistency model in a distributed system have been formalized in the CAP theorem. CAP-induced insights led developers to consider alternative consistency models, such as BASE, in order to trade off strong consistency guarantees for availability and partition tolerance, but also scalability. Looser consistency models have been popularized during recent years, in particular, by different breeds of NoSQL databases. Application’s consistency model has a major impact on the application scalability and availability, so it would be good to address this concern more explicitly in the manifesto. The chosen consistency model is a cross-cutting trait, over which all the application layers should uniformly agree. This concern is something that is mentioned in the manifesto, but since it’s such an important issue, and it has subtle implications, it would be good to elaborate it a bit more or refer to a more through discussion of the topic.

Event-driven is a widely used term in programming that can take on many different meanings and has multiple variations. Since it’s such an overloaded term, it would be good to define it more clearly and try to characterize what exactly does and does not constitute as event-driven in this context. The authors clearly have event-driven architecture (EDA) in mind, but EDA is also something that can be achieved with different approaches. The same is true for “asynchronous communication”. In the reactive manifesto “asynchronous communication” seems to imply using message-passing, as in messaging systems or the Actor model, and not asynchronous function or method invocation.

The reactive manifesto adopts and combines ideas from many movement from CAP theorem, NoSQL, event-driven architecture. It captures and amalgamates valuable lessons learned learned by the software development community in building internet-scale applications.

The manifesto makes a lot of sense, and I can subscribe to the ideas presented in it. However, on a few occasions, the terminology could be elaborated a bit and made more approachable to developers who don’t have extensive experience in scalability issues. Sometimes, the worst thing that can happen to great ideas is that they get diluted by unfortunate misunderstandings :-)



Implementing Jersey 2 Spring integration

Jersey is the excellent Java JAX-RS specification reference implementation from Oracle. Last year, when we were starting to build RESTful backend web services for a high-volume website, we chose to use the JAX-RS API as our REST framework and Spring framework for dependency injection. Jersey was our JAX-RS implementation of choice.

When the project was started JAX-RS API 2.0 specification was not yet released, and neither was Jersey 2.0. Since we didn’t see any fundamental deficiencies with JAX-RS 1.1, and because a stable Spring integration module existed for Jersey 1.1, we decided to go with the tried-and-true version instead of taking on the bleeding edge.

Still, I was curious to learn what could be gained by adopting the newer version, so I started looking at the JAX-RS 2 API on my free time and doing some prototyping with Jersey 2. I noticed that Jersey 2 lacked Spring framework integration that was available for the previous version. Studying the issue further, I found that the old Spring integration module would not be directly portable to Jersey 2. The reason was that Jersey 1 builds on a custom internal dependency injection framework while Jersey 2 had switched to HK2 for dependency injection. (HK2 is an interesting, light-weight dependency injection framework used in GlassFish.)

My original goals for Jersey-Spring integration were fairly simple:

inject Spring beans declared in application context XML into JAX-RS resource classes (using @Autowired annotation or XML configuration)

So, I thought I’d dig a bit deeper and started looking into Jersey source code. I was happy to notice that Jersey development was being done in an open and approachable manner. The source code was hosted on GitHub and updated frequently. After a while of digging, a high-level design for Jersey Spring integration started to take shape. It took quite some experimenting and many iterations before the first working prototype. At that point, being an optimist, I hoped I was nearly done and contacted the jersey-users mailing list to get feedback on the design and implementation. The feedback: add more use cases, provide sample code, implement test automation, sign Oracle Contributor Agreement :-) (The feedback, of course, was very reasonable from the Jersey software product point of view). So, while it wasn’t quite back to the drawing board, but at this point I realized the last mile was to be considerably longer than I had hoped for.

Eventually, though, the Jersey-Spring integration got merged in Jersey 2 code base in Jersey v2.2 release. The integration API is based on annotations and supports the following features:

  • inject Spring beans into Jersey managed JAX-RS resource classes (using org.springframework.beans.factory.annotation.Autowired or javax.inject.Inject). @Qualifier and @Named annotations can be used to further qualify the injected instance.
  • allow JAX-RS resource class instance lifecycle to be managed by Spring instead of Jersey (org.springframework.stereotype.Component)
  • support different Spring bean injection scopes: singleton, request, prototype. Bean scope is declared in applicationContext.xml.

The implementation

Source code for the Jersey-Spring integration can be found in the main Jersey source repository:

https://github.com/jersey/jersey/tree/2.5.1/ext/spring3/src/main/java/org/glassfish/jersey/server/spring

Jersey-Spring integration consists of the following implementation classes:

org.glassfish.jersey.server.spring.SpringComponentProvider
This ComponentProvider implementation is registered with Jersey SPI extension mechanism and it’s responsible for bootstrapping Jersey 2 Spring integration. It makes Jersey skip JAX-RS life-cycle management for Spring components. Otherwise, Jersey would bind these classes to HK2 ServiceLocator with Jersey default scope without respecting the scope declared for the Spring component. This class also initializes HK2 spring-bridge and registers Spring @Autowired annotation handler with HK2 ServiceLocator. When being run outside of servlet context, a custom org.springframework.web.context.request.RequestScope implementation is configured to implement request scope for beans.

org.glassfish.jersey.server.spring.AutowiredInjectResolver
HK2 injection resolver that injects dependencies declared using Spring framework @Autowired annotation. HK2 invokes this resolver and asks it to resolve dependencies annotated using @Autowired.

org.glassfish.jersey.server.spring.SpringLifecycleListener
Handles container lifecycle events. Refreshes Spring context on reload and close it on shutdown.

org.glassfish.jersey.server.spring.SpringWebApplicationInitializer
A convenience class that helps the user avoid having to configure Spring ContextLoaderListener and RequestContextListener in web.xml. Alternatively the user can configure these in web application web.xml.

In addition to the actual implementation code, the integration includes samples and tests, which can be very helpful in getting developers started.

The JAX-RS specification defines its own dependency injection API. Additionally, Jersey supports JSR 330 style injection not mandated by the JAX-RS specification. Jersey-Spring integration adds support for Spring style injection. Both JAX-RS injection and Spring integration provide a mechanism for binding objects into a registry, so that objects can later be looked up and injected. If you’re using a full Java EE application server, such as Glassfish, you also have the option of binding objects via the CDI API. On non-Java EE environments it’s possible to use CDI by embedding a container implementation such as Weld. Yet another binding method is to use Jersey specific API. The test code includes a JAX-RS application class that demonstrates how this can be done.

Modifying Jersey-Spring

If you want to work on Jersey-Spring, you need to check out Jersey 2 code base and build it. That process is rather easy and well documented:

https://jersey.java.net/documentation/2.5.1/how-to-build.html

You simply need to clone the repository and build the source. The build system is Maven based. You can also easily import the code base into your IDE of choice (tried it with IDEA 12, Eclipse 4.3 and NetBeans 8.0 beta) using its Maven plugin. I noticed, however, that some integration tests failed with Maven 3.0, and I had to upgrade to 3.1, but apart from that there weren’t any issues.

After building Jersey 2 you can modify the Spring integration module, and build only the changed modules to save time.

Tests

Jersey-Spring integration tests have been built using Jersey test framework and they’re run under the control of maven-failsafe-plugin. Integration tests consist of actual test code and a JAX-RS backend webapp that the tests exercise. The backend gets deployed into an external Jetty servlet container using jetty-maven-plugin. Jersey-Spring tests can be executed separately from the rest of the tests. Integration tests can be found in a separate Maven submodule here:

https://github.com/jersey/jersey/tree/2.5.1/tests/integration/spring3

In addition to demonstrating the basic features of Jersey-Spring, the tests show how to use different Spring bean scopes: singleton, request, prototype. The tests also exhibit using a JAX-RS application class for registering your own dependencies in the container, in different scopes.

Conclusions

I think the JAX-RS 2.0 API provides a nice and clean way of implementing RESTful interfaces in Java. Development of the Jersey JAX-RS reference implementation is being conducted in an open and transparent manner. Jersey also has a large and active user community.

As noted by Frederick Brooks, Jr.: “All programmers are optimists”. It’s often easy to underestimate the amount of work required to integrate code with a relative large and complex code base, and in particular when you need to mediate between multiple different frameworks (in this case Jersey, HK2, Spring framework). Also, though Jersey has pretty good user documentation, I missed high-level architectural documentation on the design and implementation. A lot of poking around was needed to be able to identify the correct integration points. Fortunately, the Jersey build system is pretty easy to use and allows building only selected parts, which makes experimenting and the change-build-test cycle relatively fast.

Both Jersey and Spring framework provide a rich set of features and you can use them together in a multitude of ways. Jersey-Spring integration in it’s current form covers a couple of basic integration scenarios between the two. If you find that your particular scenario isn’t supported, join the jersey-users mailing list to discuss it. You can also just check out the code, implement your changes and contribute them by submitting a pull request on GitHub.

Building a beacon out of Pi

Building a beacon out of Pi

iBeacon is, to quote Wikipedia, an indoor positioning system that Apple calls “a new class of low-powered, low-cost transmitters that can notify nearby iOS 7 devices of their presence. The technology is not, however, restricted to iOS devices and can currently also be used with Android devices. Many people are predicting it will change retail shopping.

At it’s core, the technology allows proximity sensing so, that a device can alert a user when moved from or to close proximity of a peer device. In a typical use case a “geo fence” is established around a stationary device (i.e. “beacon”) and mobile devices carried by users issue alerts when crossing the fence to either enter or exit the region.

After Apple’s WWDC 2013 conference we’ve seen quite a bit of a buzz about iBeacon. Interestingly, the underlying technology is based on the Bluetooth Proximity profile specification ratified in 2011. Though a lot of the buzz has been associated with Apple, the company is not attributed as a contributor to the original specification. Also, Apple is yet to reveal what it plans to do exactly with iBeacon.

A few other companies are planning to bring iBeacon compatible beacons to the market, but the beacons aren’t shipping, yet. So, if you want to start developing software right now you have to resort to other solutions. One option is to use a Bluetooth LE (BLE) capable device, equipped with the right software, as a beacon. For example BLE capable iOS devices, can act as beacons with the AirLocate application. So, if you have e.g. a new iPhone 5 to spare, you can make it into a beacon very easily. Another option is to build a beacon yourself, since iBeacons are based on standard Bluetooth LE proximity profile. A company called Radius Networks has published an article about building a beacon, so I decided to try this out.

Beacon BOM

The bill of materials for the beacon was pretty simple

  • Raspberry Pi + memory card + power cord
  • a USB Bluetooth 4.0 LE dongle

Additionally, I bought the following items to make installation easier:

  • a USB SD card reader
  • HDMI display cable
  • USB hub
beacon bill-of-materials

beacon bill-of-materials

Unfortunately, Radius was using IOGEAR GBU521 Bluetooth dongle which I couldn’t find at any of the local electronics shops. USB Bluetooth dongles aren’t very expensive, however, and since there aren’t many Bluetooth chipsets on the market, I decided to experiment a bit and buy two different dongles to try out. These were the Asus USB-BT400 and TeleWell Bluetooth 4.0 LE + EDR.

Operating system deployment

Some vendors sell memory cards with pre-installed OS for Raspberry Pi, but I couldn’t find one of those either at my local electronics shop, so I bought a blank memory card and a USB-based SD card reader, just in case. The SD card reader proved handy because it turned out the card didn’t work with the built-in reader on my MacBook Pro. Installing the Raspbian (2013-09-25-wheezy) Linux distribution was fairly straightforward using the instructions on Embedded Linux Wiki (RPi Easy SD Card Setup). The only notable issue was that on Mac OS X writing the OS image to the card was a lot faster (~ 4 min. vs. ~ 30 min.) using the raw disk device instead of the buffered one. Another issue was that the memory card disk had to be unmounted using diskutil, not ejecting it through Mac OS X Finder.

After installing the OS image on the SD card it was time to see if the thing would boot. Unfortunately, I only had a VGA monitor and no suitable HDMI-VGA adapters , so I wasn’t able to make a console connection with the Pi. Being eager to see if everything worked so far, I decided to connect the Pi to a wireless access point and power it up. After a few moments, I noticed that RasPi had acquired an IP address from the AP’s DHCP server and I was able to log in to the Pi via SSH using the default credentials. So, no console whatsoever was required to set up the Pi!

Being a Java developer, I was happy to notice that Raspbian came with a fairly recent Java Standard Edition 7 installation by default. The latest Java 8 build is also available for Raspbian.

Building the Bluetooth stack

Once the basic OS setup was done, I had to compile the BlueZ Linux Bluetooth stack which, proved to be a rather simple matter of installing the compile-time pre-requisites through RasPi package management (apt-get):

libusb-dev libdbus-1-dev libglib2.0-dev libudev-dev libical-dev libreadline-dev

and then configuring the source and building it. I used BlueZ version 5.10, which was the latest official version at the time.

After compiling the BlueZ Bluetooth protocol stack it was time to test if the Bluetooth dongles I had bought were working. Running hciconfig I noticed that the Telewell dongle was being detected, while the Asus wasn’t. During further testing it became clear that the Pi’s signal wasn’t being picked up by a demo app on an iPad. More research showed that though the TeleWell dongle did support Bluetooth 4.0 LE, it didn’t officially support the required proximity profile. After yet more googling, I found that the Asus dongle seemed to include the same Broadcom BCM20702 (A0) chipset as the IOGEAR one used by Radius Networks. However, the dongle wasn’t being detected because Asus has a vendor specific USB device ID for it that wasn’t known by the Raspbian kernel. The solution for this issue was to add the device ID in the kernel source (credit to linux-bluetooth mailing list), rebuild and install the newly built kernel.

Compiling the Linux kernel

Compiling the Linux kernel is a very time-consuming task, particularly on a resource constrained environment such as the Raspberry Pi. Fortunately, it’s possible to set up a cross-compiler environment on a more powerful system to speed things up. Again, the Embedded Linux Wiki proved to be a great resource with this task (RPi Kernel Compilation). Though, you can install a x86 / Mac OS X ⇒ ARM / Linux cross-compilation environment, I thought I’d try to go for an, arguably, more mainstream choice and set up my cross-compiler environment on a Linux Mint 15 Xfce guest virtual machine. The required packages were again available via apt-get:

gcc-arm-linux-gnueabi libncurses-dev

Additionally, Git had to be installed to be able to fetch the Raspberry Pi kernel source, build tools and firmware.

Kernel compilation for Raspberry Pi is a bit different than compiling a standard kernel for a server class machine, and is done using the following procedure:

  • fetch Raspberry Pi Linux kernel source, compiler tools and firmware
  • set up environment variables for the compilation
  • configure the kernel source (using a config file from the Pi)
  • build kernel and modules
  • package up the kernel, modules and firmware
  • deploy kernel, modules and firmware to Pi
  • reboot Pi (with fingers crossed)

Fortunately, I was able to produce and deploy a working kernel build and the Pi booted up with the fresh kernel. This time, hciconfig showed that the kernel and the Bluetooth stack were able to detect the Asus Bluetooth dongle.

Testing the beacon

There are a couple of mobile applications available that can be used for verifying that a beacon is functioning properly. iBeacon Locate is available in Google play store for Android 4.3+ users and Beacon Toolkit in Apple App Store for iOS 7.0+ users. Both applications require that the device supports Bluetooth BLE.

Sample code demonstrating how to read beacon signals is also available from multiple sources, including the AirLocate application, Apple WWDC 2013 and android-ibeacon-service. AirLocate e.g. is a complete sample app that you can build, modify and install on your iOS device, provided that you have an Apple iOS developer certificate.

I was able to pick up the Raspberry Pi’s beacon signal using AirLocate on iOS and iBeacon Locate on Android. There were some problems with the sample apps, when I configured the beacon to use a custom device UUID instead of an Apple demo UUID: the demo apps failed to detect the beacon when using custom a UUID. A custom application was, however, able to detect the beacon also with a custom UUID.

beacon ranging and proximity sensing alert

beacon ranging and proximity sensing alert

Next, I’ll have to experiment a bit more with proximity sensing accuracy, notification event delay and how different physical space topologies and interference affect proximity sensing. Also, a demo app should be developed to simulate proximity alerts in the context of a real use case.

Init scripts

Once Pi beacon was running fine, the last thing was to make the beacon automatically turn on at boot. For this I studied the existing init scripts to learn what kind of metadata is required to be able to manage the “service” using update-rc.d command. I also separated the configuration parameters in a separate file (/etc/default/ibeacon.conf) from the init script.

Final thoughts

iBeacon is based on standard Bluetooth 4.0 LE proximity profile that is not Apple proprietary technology. The technology works currently on newer iOS and Android devices, and these operating systems include APIs required to detect beacon signals. iBeacon has many interesting use cases for indoor positioning, including but not limited to, retail shopping and analytics. It’s still an emerging technology and I’m sure we’ll see it applied in many unexpected contexts in the future.

The Raspberry Pi is a device platform with intriguing possibilities. Traditionally embedded software development and server-side software development have required very different skill sets. Raspberry Pi demonstrates how the embedded platforms have evolved significantly during the last few years in terms of hardware capacity as well as software platform maturity. Consider e.g. the following points:

  • the system has “standard” support for Java as well as many other popular language runtimes, making it possible to develop software using desktop or server-side development skills and tools
  • hardware capacity is gaining on low-end server-class machines in terms of memory, CPU and storage capacity
  • the OS and other software can be updated over the network using update manager tools instead of having to flash firmware
  • it’s based on a standard Linux environment
  • the system supports remote management over secure terminal connection

With the high end embedded platforms, such as the Raspberry Pi, similar tools and techniques can be used for developing software on both platforms, so from a development and maintenance point of view these platforms are converging. This creates fascinating opportunities for software developers who don’t have a traditional embedded development skill set.

Practical NoSQL experiences with Apache Cassandra

Most of the backend systems I’ve worked with over the years have employed relational database storage in some role. Despite many application developers complaining about RDBMS performance, I’ve found that with good design and implementation a relational database can actually scale a lot further than developers think. Often software developers who don’t really understand relational databases tend to blame the database for being a performance bottleneck, even if the root cause could actually be traced to bad design and implementation.

That said, there are limits to RDBMS scalability and it can become a serious issue with massive transaction and data volumes. A common workaround is to partitioning application data based on a selected criteria (functional area and/or selected property of entities within functional area) and then distributing data across database server nodes. Such partitioning must usually be done at the expense of relaxing consistency. There are also plenty of other use cases for which relational databases in general, or the ones that are available to you, aren’t without problems.

Load-balancing and failover are sometimes difficult to achieve even on a smaller scale with relational databases, especially if you don’t have the option to license a commercial database clustering option. And even if you can, there are limits to scalability. People tend to workaround these problems with master-slave database configurations, but they can be difficult to set up and manage. This sort of configuration will also impact data consistency if master-slave replication is not synchronous, as is often the case.

When an application also requires a dynamic or open-ended data model, people usually start looking into NoSQL storage solutions.

This was the path of design reasoning for a project I’m currently working on. I’ve been using Apache Cassandra (v1.2) in a development project for a few months now. NoSQL databases come in very different forms and Cassandra is often characterized as a “column-oriented” or “wide-row” database. With the introduction of the Cassandra Query Language (CQL) Cassandra now supports declaring schema and typing for your data model. For the application developer, this feature brings the Cassandra data model somewhat closer to the relational (relations and tuples) model.

NoSQL design goals and the CAP theorem

NoSQL and relational databases have very different design goals. It’s important for application developers to understand these goals because in practice they guide and dictate the set of feasible product features.

ACID transaction guarantees provide a strong consistency model around which web applications have traditionally been designed. When building Internet-scale systems developers came to realize that strong consistency guarantees come at a cost. This was formulated in Brewer’s CAP theorem, which in its original form stated that a distributed system can only achieve two of the following properties:

  • consistency (C) equivalent to having a single up-to-date copy of the data;
  • high availability (A) of that data (for updates); and
  • tolerance to network partitions (P).

The “2 of 3” formulation was later revised somewhat by Brewer, but this realization led developers to consider using alternative consistency models, such as “Basically Available, Soft state, Eventual consistency” or BASE, in order to trade off strong consistency guarantees for availability and partition tolerance, but also scalability. Promoting availability over consistency became a key design tenet for many NoSQL databases. Other common design goals for NoSQL databases include high performance, horizontal scalability, simplicity and schema flexibility. These design goals were also shared by Cassandra founders, but it was also designed to be CAP-aware, meaning the developer is allowed to tune the tradeoff between consistency and latency.

BASE is a consistency model for distributed systems that does not require a NoSQL database. NoSQL databases that promote the BASE model also encourage applications to be designed around BASE. Designing a system that uses BASE consistency model can be challenging from technical perspective, but also because relaxing consistency guarantees will be visible to the users and requires a new way of thinking from the product owner, who traditionally are accustomed to thinking in terms of a strong consistency model.

Data access APIs and client libraries

One of the first things needed when starting to develop a Java database application is a database client library. With most RDBMS products this is straightforward: JDBC is the defacto low-level database access API, so you just download a JDBC driver for that particular database and configure your higher level data access API (e.g. JPA) to use that driver. You get to choose which higher level API to use, but there’s usually only a single JDBC driver vendor for a particular database product. Cassandra on the other hand currently has 9 different clients for Java developers. These clients provide different ways of managing data: some offer an object-relational -mapping API, some support CQL and others provide a lower level (e.g. Thrift based) APIs.

Data in Cassandra can be accessed and managed using an RPC-style (Thrift based) API, but Cassandra also has a very basic query language called CQL that resembles SQL syntactically to some extent, but in many cases the developer is required to have a much deeper knowledge of how the storage engine works below the hood than with relational databases. The Cassandra community recommended API to use for new projects using Cassandra 1.2 is CQL 3.

Since Cassandra is being actively developed, it’s important to pick a client whose development pace matches that of the server. Otherwise you won’t be able to leverage all the new server features in your application. Because Cassandra user community is still growing, it’s good to choose a client with an active user community and existing documentation. Astyanax client, developed by Netflix, currently seems to be the most widely used, production-ready and feature complete Java client for Cassandra. This client supports both Thrift and CQL 3 based APIs for accessing the data. DataStax, a company that provides commercial Cassandra offering and support, is also developing their own CQL 3 based Java driver, which recently came out of beta phase.

Differences from relational databases

Cassandra storage engine design goals are radically different from those of relational databases. These goals are inevitably reflected in the product and APIs, and IMO neither can nor should be hidden from the application developer. The CQL query language sets expectations for many developers and may make them assume they’re working with a relational database. Some important differences to take note of that may feel surprising from an RDBMS background include:

  • joins and subqueries are not supported. The database is optimized for key-oriented access and data access paths need to be designed in advance by denormalization. Apache Solr, Hive, Pig and similar solutions can be used to provide more advanced query and join functionality
  • no integrity constraints. Referential and other types of integrity constraint enforcement must be built into the application
  • no ACID transactions. Updates within a single row are atomic and isolated, but not across rows or across entities. Logical units of work may need be split and ordered differently than when using RDBMS. Applications should be designed should to be designed for eventual consistency
  • only indexed predicates can be used in query statements. An index is automatically created for row keys, indexes in other column values can be created as needed (except currently for collection typed columns). Composite indexes are not supported. Solr, Hive etc. can be used to address these limitations.
  • sort criteria needs to be designed ahead. Sort order selection is very limited. Rows are sorted by row key and columns by column name. These can’t be changed later. Solr, Hive etc. can be used to address these limitations.

Data model design is a process where developers will encounter other dissimilarities compared to the RDBMS world. For Cassandra, the recommended data modeling approach is the opposite of RDBMS: identify data access patterns, then the model data to support those access patterns. Data independence is not a primary goal and developers are expected to understand how the CQL data model maps to storage engine’s implementation data structures in order to make optimal use of Cassandra. (In practice, full data independence can be impossible to achieve with high data volume RDBMS applications as well). The database is optimized for key-oriented data access and data model must be denormalized. Some aspects of the application that can be easily modified or configured at runtime in relational databases are design time decisions with Cassandra, e.g. sorting.

A relational application data model typically stores entities of a single type per relation. The Cassandra storage engine does not require that rows in a column family contain the same set of columns. You can store data about entirely unrelated entities in a single column family (wide rows).

Row key, partition key and clustering column are data modeling concepts that are important to understand for the Cassandra application developer. The Cassandra storage engine uniquely identifies rows by row key and keys provide the primary row access path. A CQL single column primary key maps directly to a row key in the storage engine. In case of a composite primary key, the first part of the primary key is used as the row key and partition key. The remaining parts of a composite primary key are used as clustering columns.

Row key and column name, along with partitioner (and comparator) algorithm selection have important consequences for data partitioning, clustering, performance and consistency. Row key and partitioner control how data is distributed among nodes in the database cluster and ordered within a node. These parameters also determine whether range scanning and sorting is possible in the storage engine. Logical rows with the same partition key get stored as a single, physical wide row, on the same database node. Updates within a single storage engine row are atomic and isolated, but not across rows. This means that your data model design determines which updates can be performed atomically. Columns within a row are clustered and ordered by the clustering columns, which is particularly important when the data model includes wide rows (e.g. time-series data).

When troubleshooting issues with an application, it’s often very important to be able to study the data in the storage engine using ad-hoc queries. Though Cassandra does support ad-hoc CQL queries, the supported query types are more limited. Also, the database schema changes, data migration and data import typically require custom software development. On the other hand, schema evolution has traditionally been very challenging with RDBMS when large data volumes have been involved.

Cassandra supports secondary indexes, but applications are often designed to maintain separate column families that support looking up data based on a single or multiple secondary access criteria.

One of the interesting things I noticed about Cassandra was that it has really nice load-balance and failover clustering support that’s quite easy to setup. Failover works seamlessly and fast. Cassandra is also quite lightweight and effortless to set up. Data access and manipulation operation performance is extremely fast in Cassandra. The data model is schema-flexible and supports use cases for which RDMBS usually aren’t up to the task e.g. storing large amounts of time-series data with very high performance.

Conclusions

Cassandra is a highly available, Internet-scale NoSQL database with design goals that are very different from those of traditional relational databases. The differences between Cassandra and relational databases identified in this article should each be regarded as having pros and cons and be evaluated in the context of the your problem domain. Also, using NoSQL does not exclude the use of RDBMS – it’s quite common to have a hybrid architecture where each database type is used in different use cases according the their strengths.

When starting their first NoSQL project, developers are likely to enter new territory and have their first encounters with related concepts such as big data and eventual consistency. Relational databases are often associated with strong consistency, whereas NoSQL systems are associated with eventual consistency (even though the use of a certain type of database doesn’t imply a particular consistency model). When moving from the relational world and strong consistency to the NoSQL world the biggest mind shift may be in understanding and architecting an application for eventual consistency. Data modeling is another area where a new way of design thinking needs to be adopted.

Cassandra is a very interesting product with a wide range of use cases. I think it’s particularly well suited database option for the following use cases:

  • very large data volumes
  • very large user transaction volumes
  • high reliability requirements for data storage
  • dynamic data model. Data model may be semi structured and expected see significant changes over time
  • cross datacenter distribution

It is, however, very different from relational databases. In order to be able to make an informed design decision on whether to use Cassandra or not, a good way to learn more is to study the documentation carefully. Cassandra development is very fast paced, so many of the documents you may find could be outdated. There’s no substitute for hands-on experience, though, so you should do some prototyping and benchmarking as well.

Java VM Options

Some of the more frequently used Java HotSpot VM Options have been publicly documented by Oracle.

Of those flags the following are the ones I tend to find most useful for server-side Java applications:

  • -XX:+UseConcMarkSweepGC – select garbage collector type
  • -XX:+HeapDumpOnOutOfMemoryError -XX:HeapDumpPath=$APP_HOME_DIR – when an out-of-memory error occurs, dump heap
  • -XX:OnOutOfMemoryError=<command_for_processing_out_of_memory_errors> – execute user configurable command when an out-of-memory error occurs
  • -XX:OnError=<command_for_processing_unexpected_fatal_errors> – execute user configurable command when an unexpected error occurs
  • -XX:+PrintGCDetails -XX:+PrintGCTimeStamps – increase garbase collection logging
  • -Xloggc:$APP_HOME_DIR/gc.log – log garbage collection information to a separate log file
  • -XX:-UseGCLogFileRotation -XX:GCLogFileSize=<max_file_size>M -XX:NumberOfGCLogFiles=<nb_of_files> – set up log rotation for garbage collection log

Occasionally, the following might also be helpful to gain more insight into what the GC is doing:

  • -XX:PrintHeapAtGC
  • -XX:PrintTenuringDistribution

Oracle documentation covers quite a few HotSpot VM flags, but every once in a while you bump into flags that aren’t on the list. So, you begin to wonder if there’re more JVM options out there.

And, in fact, there’s a lot more as documented by this blog entry: The most complete list of -XX options for Java JVM

That list is enough to make any JVM application developer stand in awe :-)
There’s enough options to shoot yourself in the foot, but you should avoid the temptation of employing each and every option.

Most of the time it’s best to use only the one’s you know are needed. JVM options and their default values tend to change from release to release, so it’s easy to end up with a huge list of flags that suddenly may not be required at all with a new JVM release, or worse,  may even result in conflicting or erroneous behavior. The implications of some of the options, the GC one’s in particular, and the way that related options interact with each other may sometimes be difficult. Using a minimal list of options is easier to understand and maintain. Don’t just copy-paste options from other applications without really understanding what they’re for.

So, what’re your favorite options?

Mine would probably be -XX:SelfDestructTimer ;-)
(No, there really is such an option and it does work)

Advanced PostgreSQL features

Nearly all the server-side development projects I’ve worked in over the years have stored at least part of their data in a relational database system. Even the systems using NoSQL storage have included a RDBMS in some form, whether local to a single subsystem or in a large role. In some cases the RDBMS systems have been proprietary, but increasingly they’ve been open source projects.

I’ve been using PostgreSQL in projects with RDBMS storage requirements on and off over the years. It has often impressed me with its depth of support for the SQL standard as well as wide range of non-standard extension features. With other widely used OSS RDBMS engines, I’ve often noticed that while the database claims to support feature X on paper, it only supports a subset. And then there’s a list of limitations you need to account for. Typically those limitations are something you wouldn’t expect, so they come as a surprise. Subqueries and joins are one such feature.

With PostgreSQL, I haven’t yet found a case where the database wouldn’t be able to handle a SQL standard subquery or join statement. Having an item such as comprehensive support for SQL subqueries and joins in a database product feature list may not look particularly appealing, it may even raise some suspicions. But from a developer point of view I find this “feature” a very important one, perhaps even one of PostgreSQL’s biggest selling points compared to some of it’s OSS competitors. PostgreSQL has many other advanced features that are interesting for application developers.

Common table expressions and hierarchic queries

Common table expressions or CTE is a handy standard SQL feature that allows you to split a query statement into distinct parts where results of each part will appear as a table, so you can reference the intermediate results in other parts of the statement, possibly several times. This can help make query statements more maintainable, but it also helps optimize queries in some cases, since CTE expressions are performed only once per statement execution.

In addition to allowing subquery factoring, CTE can process data as hierarchical. With small amounts of data and relatively shallow hierarchies you can implement hierarchical queries simply using joins, but this workaround may not be acceptable in all cases. A CTE hierarchical query makes it possible to process arbitrarily deep hierarchies with just one query.

Here’s an example how you can get a list of subtasks in an arbitrarily deep task tree along with path information for each task. Including path information will make it easier to build a graph representation on the receiving end.

mydb=> WITH RECURSIVE task_tree (id, name, parent_id, depth, path) AS (
mydb(>   SELECT id, name, parent_id, 1, ARRAY[t.id]
mydb(>     FROM task t WHERE t.id = 1
mydb(>   UNION ALL
mydb(>   SELECT s.id, s.name, s.parent_id, tt.depth + 1, path || s.id
mydb(>     FROM task s, task_tree tt WHERE s.parent_id = tt.id
mydb(> )
mydb-> SELECT * FROM task_tree
mydb-> ORDER BY depth ASC;

 id |    name     | parent_id | depth |    path
----+-------------+-----------+-------+-------------
  1 | task1       |           |     1 | {1}
  4 | task1-1     |         1 |     2 | {1,4}
  5 | task1-2     |         1 |     2 | {1,5}
  6 | task1-3     |         1 |     2 | {1,6}
 13 | task1-3-1   |         6 |     3 | {1,6,13}
 14 | task1-3-1-1 |        13 |     4 | {1,6,13,14}
(6 rows)

PostgreSQL also has an extension module that allows handling hierarchic data in a less verbose, but non-standard manner:

mydb=> SELECT * FROM connectby('task', 'id', 'parent_id', '1', 0, '/')
mydb->  AS t(id BIGINT, parent_id BIGINT, level INT, branch TEXT);

 id | parent_id | level |  branch
----+-----------+-------+-----------
  1 |           |     0 | 1
  4 |         1 |     1 | 1/4
  5 |         1 |     1 | 1/5
  6 |         1 |     1 | 1/6
 13 |         6 |     2 | 1/6/13
 14 |        13 |     3 | 1/6/13/14
(6 rows)

Aggregates and window functions

SQL GROUP BY lets you calculate aggregates of data over a single or multiple columns in a result set. The clause, however, can only aggregate over a single grouping, so it wouldn’t be possible e.g. to get calculate average salaries over departments and locations in a single query. Another limitation is that only aggregated data is returned and detail data is not preserved, so you can’t get both the detail records and aggregates using a single query.

Window functions make it possible to get both. Here’s how to calculate employee salary aggregates over several different groupings while preserving the detail records:

mydb=> SELECT depname, location, empno, salary,
mydb-> AVG(salary) OVER (PARTITION BY depname) avgdept,
mydb-> SUM(salary) OVER (PARTITION BY depname) sumdept,
mydb-> AVG(salary) OVER (PARTITION BY location) avgloc,
mydb-> RANK() OVER (PARTITION BY depname ORDER BY salary DESC, empno) AS pos
mydb-> FROM empsalary;

  depname  | location | empno | salary |        avgdept        | sumdept |        avgloc         | pos
-----------+----------+-------+--------+-----------------------+---------+-----------------------+-----
 develop   | fi       |     8 |   6000 | 5020.0000000000000000 |   25100 | 4550.0000000000000000 |   1
 develop   | se       |    10 |   5200 | 5020.0000000000000000 |   25100 | 4950.0000000000000000 |   2
 develop   | fi       |    11 |   5200 | 5020.0000000000000000 |   25100 | 4550.0000000000000000 |   3
 develop   | fi       |     9 |   4500 | 5020.0000000000000000 |   25100 | 4550.0000000000000000 |   4
 develop   | fi       |     7 |   4200 | 5020.0000000000000000 |   25100 | 4550.0000000000000000 |   5
 personnel | fi       |     2 |   3900 | 3700.0000000000000000 |    7400 | 4550.0000000000000000 |   1
 personnel | fi       |     5 |   3500 | 3700.0000000000000000 |    7400 | 4550.0000000000000000 |   2
 sales     | se       |     1 |   5000 | 4866.6666666666666667 |   14600 | 4950.0000000000000000 |   1
 sales     | se       |     3 |   4800 | 4866.6666666666666667 |   14600 | 4950.0000000000000000 |   2
 sales     | se       |     4 |   4800 | 4866.6666666666666667 |   14600 | 4950.0000000000000000 |   3
(10 rows)

Like CTE, window functions is a feature specified in the SQL standard, but it’s not supported by all OSS or proprietary RDBMS systems.

Pivoting data

Sometimes it’s nice to be able to pivot data in a properly normalized data model, so that repeating groups of related entities are folded into parent entity as columns. This can be useful e.g. for reporting purposes and ad-hoc queries. PostgreSQL can handle pivoting data using subqueries and arrays like this:

mydb=> SELECT e.*,
mydb-> (SELECT ARRAY_TO_STRING(ARRAY(SELECT emp_phone_num FROM emp_phone p WHERE e.employee_id = p.emp_id), ',')) AS phones
mydb->  FROM employees AS e;

 employee_id | last_name | manager_id |         phones
-------------+-----------+------------+-------------------------
         100 | King      |            |
         101 | Kochhar   |        100 | 555-123,555-234,555-345
         108 | Greenberg |        101 | 555-111
         205 | Higgins   |        101 | 555-914,555-222
         206 | Gietz     |        205 |
...
(13 rows)

Another way is to use the tablefunc extension module again:

mydb=> SELECT *
mydb-> FROM crosstab(
mydb(>   'SELECT emp_id, contact_type, contact FROM emp_sm_contact ORDER BY 1',
mydb(>   'SELECT DISTINCT contact_type FROM emp_sm_contact ORDER BY 1'
mydb(> )
mydb-> AS emp_sm_contact(emp_id BIGINT, "g+" TEXT, "linkedIn" TEXT, twitter TEXT);

 emp_id |    g+     | linkedIn  | twitter
--------+-----------+-----------+---------
    100 | bking     | b.king    | beking
    101 | kochhar.2 | kochhar.1 | kochhar
    200 |           |           | whalen
(3 rows)

Other advanced features

Other advanced PostgreSQL features that I find of interest to application developers include:

  • pattern matching. Regular expression matching is supported
  • geolocation queries. PostGIS extension adds comprehensive support for managing and querying geospatial data
  • partitioning
  • replication

Final thoughts

Problems faced in the transition phase of the software development process, when the software has been handed over from development to operations team, have prompted the need for closer collaboration between the teams in the form of devops culture. Similarly, application developers can’t remain ignorant of database design, implementation and optimization issues, and expect the DBAs to magically fix any data tier related design issues after the system has been implemented. Application developers need to learn how to leverage database systems effectively and take responsibility of database tier design to make transitions more seamless and production deployments succeed.

While standards based object relational mapping (ORM) technologies, such as Java persistence API, can be a great help to application developers, developers should be aware of what kind of queries the ORM implementation is generating, and in particular watch out for N+1 queries issues. With higher data, transaction volumes or data access patterns advanced database features will be a significant help in optimising the application.

To quote Oracle guru Tom Kyte: it’s a database, not a data dump. PostgreSQL is an advanced relational database engine and it has a lot of features that can help application developers implement new features faster and in a more efficient and scalable manner. As with all the tools: you should learn how to use it to get the most out of it.

More info

Tomcat JDBC Connection Pool

tomcat-jdbc is a relatively new entrant to the Java JDBC connection pool  game. It’s been designed to be a drop-in replacement for commons-dbcp.

Many of the popular Java connection pool implementations have become quite stagnant over the years, so it’s nice to see someone make a fresh start in this domain. tomcat-jdbc code base is small and has minimal dependencies. It has configurable connection validation (validation policy, query and intervals) and enables automatically closing connections after they reach a configurable maximum age.

Some time ago, we started having problems with a near end-of-life legacy application that was migrated to a new environment. The application was a standalone Java app that used commons-dbcp as its JDBC connection pool implementation. After the migration, MySQL connections started failing occasionally. This appeared to happen with a somewhat regular interval of a few hours. Since tomcat-jdbc API is compatible with commons-dbcp we were able to replace the connection pool without any code changes and configure the new pool to automatically close connections once they had been open for a certain period of time. This turned out to be an effective and nonintrusive workaround for the issue.

I hope the Tomcat development team would more actively promote using tomcat-jdbc also outside of Tomcat. The pool implementation doesn’t currently seem to be available as a separate download or from Maven central, which is likely to hinder its adoption.

A JVM polyglot experiment with JRuby

The nice thing about hobby technology projects is that you get to freely explore and learn new things. Sometimes this freedom makes the project go off at a tangent, and it’s in those cases in particular when you get to explore.

Some time ago I was working on a multi-vendor software development project. We had trouble making developers follow Git commit message guidelines and asking multiple times didn’t help, so I thought I’d implement a technological solution for this. Our repositories were hosted at GitHub, so I studied the post-receive hooks mechanism, learned a bit of Ruby and implemented my own service hook that validates the message format against a configurable format, generates an email using a configurable template and delivers it to selected recipients. Post-receive hooks don’t prevent people from committing with invalid messages, but I chose to go with a centralized solution that would not require every developer to configure their repository. I submitted my module, test code and documentation to GitHub, but the service hook implementation was rejected.

After the dead-end, I decided to try enforcing a commit message policy using a server-side hook that could actually prevent invalid commits. That solution was technically viable, but as suspected, it turned out that not all developers were willing to configure the hook in their repository. Also, every once in awhile when developers do a clean clone of the repository, the configuration needs to be redone.

So, I decided to study how service hooks could be run on an external system instead of being hosted on GitHub. The “WebHook” service hook allows you to deliver the post-receive event anywhere over HTTP. GitHub also makes service hook implementations available to be run on your own servers. The easy way would’ve been to simply take my custom service hook implementation and run it on our server. In addition to being too easy, there were some limitations with this approach as well:

  • a github-services server instance can only have a single configuration i.e. you can’t serve multiple repositories each with different configurations
  • the github-services server dispatches data it receives to a single service based on the request URL. It’s not possible to dispatch the data to a set of services.
  • you have to code service hooks in Ruby

I had heard of JRuby at that time, but didn’t have practical experience with it. After some experimenting I was able to validate my assumption that GitHub Service implementations could, in fact, be run with JRuby. At that point I started migrating the code base into a polyglot GitHub Services container that allows you to run the GitHub provided github-services as well as your own custom service implementations. Services can be implemented in different languages and run simultaneously in the same container instance. The container can be configured with an ordered set of services (chain) to handle post-receive events from one or more GitHub repositories. It’s also possible to configure a single container with separate service chains, each bound to a different repository. The container is run in Jetty servlet container and uses JRuby for executing Ruby code.

Below is an illustration of an example configuration scenario where two GitHub repositories are set up to deliver post-receive events to a single container. The container has been configured with a separate service chain for each repository.

ghj-diagram

The current status of the project is that a few GitHub Services as well as my custom Ruby and Java based services have been tested and seem to be working.

Lessons learned

The JVM can run code written in a large number of different programming languages and it’s a great platform for both dynamic language implementers and polyglot application developers. To quote JRuby developer Charles Nutter:

The JVM is going to be the best VM for building dynamic languages, because it already is a dynamic language VM.

Java 7 delivered vastly improved support for dynamic language implementers with JSR 292 or the invokedynamic bytecode instruction. Java 8 is expected to further improve language interoperability and performance.

JRuby is an interesting alternative Ruby implementation for the JVM. It’s mature and the performance benchmark numbers are impressive (Why JRuby) compared with Ruby MRI. Performance is expected to get even better with invokedynamic optimization work being done for Java 8.

While taking the existing Ruby based github-services and making them run on JRuby was successful and didn’t require any code changes, there were lots of small issues that took a surprising amount of time to resolve. Many of the issues were related to setting up the runtime environment in one way or another. High-level troubleshooting strategies are similar from platform to platform, but on a more detailed level the methods and tools are often quite different, and many of the problems I encountered might have been easier to crack with solid Ruby experience.

Here’re some lessons learned during the project:

  • Learning how to use the JRuby embedding API. There’re 3 different APIs to choose from: Red Bridge, JSR 223 and BSF. Performing tasks like instantiating objects and passing parameters in a Java call-out was not immediately obvious at first using Red Bridge
  • Figuring out concurrency / thread-safety properties of different areas of the JRuby embedding API. JRuby concurrency documentation was lacking at the time when the project was started.
  • JRuby tooling. Tooling works somewhat different from Ruby.
  • bootstrapping GitHub services gem environment
    • in order to keep the github-services installation self-contained, I wanted to install as many gems as possible in the github-services vendor directory instead of installing them in JRuby. Some gems had to be installed in JRuby while others could be installed in vendor tree.
    • some gems need to be replaced by JRuby specific ones (e.g. jruby-openssl)
    • setting up Ruby requires and load paths
    • Gems implemented as native extensions require a compiler toolchain as well as gem module library dependencies to be installed.
  • bypassing the Sinatra web app framework that’s used by github-services

Probably, most of the issues I encountered were related to bootstrapping GitHub services gem environment in some way.

Code for the experiment can be found from https://github.com/marko-asplund/github-hook-jar

JavaOne 2012 – Technical sessions

While trying to find information about technical sessions presented in JavaOne 2011 and earlier I noticed there was surprisingly little details available. Many of the results I got from googling were pointing to the JavaOne 2012 site or the links were broken. So, even though it’s been a while since the conference, I thought I’d post some notes about the themes for historical reference.

The technical sessions (487) were classified in the following tracks:

  • Core Java Platform (146 sessions)
  • Development Tools and Techniques (212 sessions)
  • Emerging Languages on the JVM (44 sessions)
  • Enterprise Service Architectures and the Cloud (112 sessions)
  • Java EE Web Profile and Platform Technologies (123 sessions)
  • Java ME, Java Card, Embedded, and Devices (62 sessions)
  • JavaFX and Rich User Experiences (70 sessions)

The numbers were from Oracle’s Schedule builder application.

Some of the hot topics in JavaOne 2012 were thin server architecture, REST, HTML 5, NoSQL, data grids, big data, polyglot, mobile web and cloud. There was also a lot of interest on next big things on the Java platform roadmap, especially Java SE 8 (Lambdas) and Java EE 7 related talks.

In addition to the new and exciting topics, the evergreen topics such as troubleshooting and optimization (esp. garbage collection), scalability, parallellism, design and design patterns seemed to draw a lot of attention.

Follow

Get every new post delivered to your Inbox.
